120 Degree 48W Round Surface Mounted LED Panel Light with CE FCC 3700LM CRI80

Name: 120 Degree 48W Round Surface Mounted LED Panel Light with CE FCC 3700LM CRI80
Brand: ZLONE
Price: 1 USD

Brand Name : ZLONE

Model Number : ZLRP6004048WS

Certification : CE ROHS TUV SGS SAA FCC

Place of Origin : China

MOQ : none

Price : negotiable

Payment Terms : T/T, Western Union

Supply Ability : 50000pcs/Month

Delivery Time : 7-10working days

Packaging Details : 3pcs/CTN 720*25*720mm /CTN N.W: 4.8KGS G.W:18kgs/ CTN

Size : 600x600x40mm

Power : 48W

Lumen : 3600-3800LM

Shape : Flat Surface mounting

Working Temperature : -25℃-+55℃

Driver THD : <15%

LED Brand : EPISTAR SMD2835

Lifespan : 50000Hours

Contact Now

600x600mm 48W Round Surface Mounted Led Panel with CE, FCC, 3700LM, CRI80

48W 600x600mm round surface mounted panel specf.

Part No.	ZLRP6004048WS
Optics Parameters	Light Source	288pcs SMD2835 EPISTAR
	Luminous Flux(lm)	3600-3800LM
	CCT(K)	warmwhtie(3000K)/white(6000K)/ Neturalwhite4000K
	CRI(Ra)	more than 80Ra
	Beam Angle	120 degree
	Light Attenuation ratio (%)	less than 3% in 30,000Hrs
	Lifespan (Hrs)	more than 50,000Hrs
Electric Parameters	Input Voltage(V)	85-265Vac
	Frequency(Hz)	50/60 Hz
	Input Current(mA)	950mA (@ 220 Vac )
	Total Power(W)	48W
	Power Factor	0.95
	Turn-on Time(S)	less than 0.05 S (@ 220Vac)
	Dielectric Voltage Withstand Test	3750Vac/1min
Structure Parameters	Material	Aluminum+ PMMA
	Size(mm)	600x600x40mm
	Net Weight(g)	4.7KG
	Water Proof(IP)	Indoor Use Only IP44
Integrated Parameters	Operating Temperature	-40 ~ +55 Centigrade
	Storage Humidity	0% ~ 95%R.H.
	Dimmable	Optional

About the Driver:

Driver used Isolated Constant Current Driver with PF>0.95, THD<15%, CE/RoHS approval

3-Year warranty.

IES Test result:

120 Degree 48W Round Surface Mounted LED Panel Light with CE FCC 3700LM CRI80

Product Application:
1:Hotels, Conference, Meeting rooms
2:Factories & Offices
3:Commercial Purposes
4:Residential/institution Buildings
5:Schools, Colleges & Universities, Hospitals
6:Other lighting use

120 Degree 48W Round Surface Mounted LED Panel Light with CE FCC 3700LM CRI80
